Y516-C Oil-in-water Sensor (Crude Oil)

  • Product Model:Y516-C
  • Time: 2023-05-11 15:30:11
  • Product description:Yoesemitech Y516-C online Oil in Water Sensor use the principle of ultraviolet fluorescence technique with high sensitivity. Less Expensive. More Accurate.

Overview

Yoesemitech Y516-C Online Oil in Water Sensor and Detector adopts the measuring principle of ultraviolet fluorescence method with high sensitivity. Compared with other water quality monitoring methods, the fluorescence method is proven to be more efficient, fast and repeatable, which can be used to detect solubility and emulsification. This oil-in-water sensor is suitable for oil field monitoring, industrial circulating water, condensate water, wastewater treatment, surface water station and many other water quality measurement scenes.

Features

-RS - 485 output, Modbus protocol compatible;
-With automatic cleaning wiper, eliminate influence of oil on the measurement;
-Reduce contamination without interference by the light interference from the outside world;
-Not affected by particles of suspended matter in water.

Specifications

NameOil in Water Sensor
ModelY516-C
Measuring principleUltraviolet fluorescence method
Range0-50ppm or 0-150ppm
LinearityR²>0.999
Resolution0.01ppm
Temperature range0-50℃
Maximum water depth30m
IP rangeIP68
InterfaceRS-485,MODBUS protocol
Power supply0.2W(non-wiping)0.6W(wiping);DC 5-12V,>500mA
SizeΦ45mm*190.8mm
Cable length10 m (default), customizable
Calibration0-point or 1-point or 2-point calibration
Sensor housing material316L(Ti)
